Description
1. Working frequency: FRS
2. Output power: less than or equal to 2W
3. Channel: 22
4. FM type: FM (F3E)
5. Antenna gain: 1.8dBi
6. Bandwidth: 12.5KHz
7. Power supply: DC3.7V
8. Thin shape, ergonomic design, relieve fatigue caused by long-term use
9. Functions: timeout timer, power saving, low battery warning, QT and DQT, VOX, channel lock, busy channel lock, signal reminder, channel display, battery status, etc.
10. Size: 136x56x21mm
Transmitter:
1. Deviation: less than or equal to +/-5KHz
2. Residual radiation: less than 60Db
3. Current: less than or equal to 1000mA
Receiver:
1. Intermodulation: 50dB
2. Audio power: greater than or equal to 300Mw
3. Current: less than or equal to 100mA
4. Squelch current: 20mA
Specification:
| Package Weight |
| One Package Weight |
0.42kgs / 0.92lb |
| One Package Size |
22cm * 17cm * 5cm / 8.66inch * 6.69inch * 1.97inch |
| Carton Weight |
9.80kgs / 21.61lb |
| Carton Size |
22cm * 34cm * 50cm / 8.66inch * 13.39inch * 19.69inch |
| Loading Container |
20GP: 713 cartons * 20 pcs = 14260 pcs
40HQ: 1655 cartons * 20 pcs = 33100 pcs
|
|
