Description
1. Scope of work: Current (0-2.5A) can detect mobile phone charger voltage compliance DC5V
2. Scope of work: U = 3~7.5V I = 0~3A
3. Resolution: Voltage 10mV current 1mA
4. Error: voltage <+/- 1% current <+/- 2%
5. Full scale drop: When (measuring current 200mV)
6. Operating temperature: 0-60 degree C
7. The tester uses a new generation of power four semi-double loop integral converter IC, with a precision bandgap reference, range accuracy, high precision, stable and reliable performance, strong anti-interference ability, high temperature can be used for measuring USB powered or power consumption of the interface, mobile phone charger, U disk and other products.
8. It can be used to measure an empty USB-powered devices, voltage loads, USB terminal equipment working voltage and current.
9. Current and voltage cycle, easy to use and practical.
Specification:
| Package Weight |
| One Package Weight |
0.03kgs / 0.06lb |
| One Package Size |
6.5cm * 2.5cm * 1.5cm / 2.56inch * 0.98inch * 0.59inch |
| Carton Weight |
9.00kgs / 19.84lb |
| Carton Size |
35cm * 27cm * 17cm / 13.78inch * 10.63inch * 6.69inch |
| Loading Container |
20GP: 1659 cartons * 500 pcs = 829500 pcs
40HQ: 3853 cartons * 500 pcs = 1926500 pcs
|
|
