Industrial RS232/RS485 to Ethernet Converter, Dual Serial Ports, Easy-to-use, High-speed, Low-power, High-stability, UpgradableOverviewThe RS232/485 TO ETH is an industrial RS232/RS485 to Ethernet converter, which allows bi-directional transparent data transmission between RS232/RS485 and RJ45 port Ethernet, even at the same time, it can be configured via webpage.Features1. M4 series 32-bit ARM processor with up to 120MHz frequency, fast speed, stable and reliable2. 10/100M Auto-MDI/MDIX ethernet interface, regardless of cross-over or straight-through cable3. Both RS232 and RS485 interface, allows to work independently at the same time, without interfering each other4. Configurable baudrate (600bps~230.4Kbps), supports five parity check options: None, Odd, Even, Mark, Space5. Multi indicators, for monitoring communicating and working status6. Available working modes: TCP Server, TCP Client, UDP Server, UDP Client, HTTPD Client (supports GET and POST)7. Support Modbus, suit for industrial application8. Support Websocket, allows bi-directional transparent data transmission with RS232/RS485 port via webpage directly9. Configurable via webpage, AT commands, serial protocol, and network protocol, provides configuration protocol which can be integrated to your own software10. Support customized heartbeat packets, make sure the connection is truthful, as well as for actively retrieving sensor data11. Support customized registration packets, auto passing the registered packet as identifier after the connection is established, so that different devices can be distinguished12. Support customized webpage, allows user to customize the module configuration page13. Support RFC2217-like protocol, be able to communicate with devices whose serial setting (baudrate, data bit, etc.) may change14. KeepAlive mechanism, detects broken connection, auto re-connecting15. Support time-out reboot (no-data reboot), ensures a long-term stable connection, configurable reboot time16. Support DNS domain name resolution, configurable DNS server17. Support DHCP, auto-obtained IP or static IP18. Firmware is upgradable via the network19. Restore to factory settings via software and/or hardware20. Comes with default MAC address, which is customizable21. Provided software: module configuration software, TCP/UDP testing tool, VCOM virtual serial port software22. Example code: host computer (socket ), VB, C++, Delphi, Android, iOS, etc.Specifications1. Ethernet:- Connector: 4-pin RJ45- Communication rate: 10/100Mbps- Interface protection: 2KV electromagnetic isolation- Protocols: IP, TCP, UDP, ARP, ICMP, DHCP, DNS, HTTPD Client, Websocket- TX cache: 16Kbyte- RX cache: 16Kbyte2. RS485/RS232:- Connector:-- RS485: screw terminal (A+, B-, GND)-- RS232: DB9 male- Data bit: 5bit, 6bit, 7bit, 8bit- Stop bit: 1, 2- Parity bit: None, Odd, Even, Mark, Space- Baudrate: 600bps~230.4Kbps- TX cache: 2Kbyte- RX cache: 2Kbyte- Hardware flow control: RTS/CTS- Interface protection:-- RS485: 2KV ESD protection, lightning-proof, anti-surge, over-current protection-- RS485 pull up/down registers: 2.2KΩ3. Power:- Power supply: 5.0~36.0V (5V recommended)- Operating current: 86.5mA (@5V)- Power consumption: <1W- Interface protection: reverse-proof, ESD protection, anti-surge4. Environment:- Operating temperature: -40~85 degree C- Storage temperature: -40~105 degree C5. Size: 85.70*82.76*25.20mmPackage Contents1.RS232/485 TO ETH x12. 5V power adapter x13. Ethernet cable x14. Male-to-Female serial cable x15. Female-to-Female serial cable x1Specification:
Package Weight
One Package Weight
0.56kgs / 1.23lb
One Package Size
15cm * 12cm * 5cm / 5.91inch * 4.72inch * 1.97inch
Qty per Carton
40
Carton Weight
24.50kgs / 54.01lb
Carton Size
50cm * 32cm * 27cm / 19.69inch * 12.6inch * 10.63inch
Loading Container
20GP: 617 cartons * 40 pcs = 24680 pcs40HQ: 1432 cartons * 40 pcs = 57280 pcs
